The world of audio technology is constantly evolving, and FiiO has consistently been at the forefront of this evolution. With the introduction of the FiiO BTR13, FiiO has once again proven its ability to combine affordability with high-quality audio performance. This small, feature-packed device serves as a Bluetooth and USB DAC (Digital-to-Analog Converter) and a headphone amplifier, delivering an impressive sound quality that appeals to both audiophiles and casual listeners. Priced at just $64, the BTR13 is an incredible value, offering versatility, advanced technology, and a powerful output in a compact, portable design. Let’s explore the features and performance of this little powerhouse in greater detail.
Technical Specifications
| Specification | Details |
| Bluetooth Chip | QCC5125 (CPU+DSP dual-core architecture) |
| DAC | CS43131 x 2 |
| Bluetooth Version | 5.1 |
| Bluetooth Codecs Supported | AAC, SBC, aptX, aptX LL, aptX Adaptive, apt HD, LDAC |
| USB DAC | Driver-free PCM 96k |
| Display | 0.96-inch, 80×160 color IPS |
| Headphone Outputs | Single-ended 3.5mm + Balanced 4.4mm |
| In-line Controls | Supports CTIA standard; play/pause/volume controls supported |
| Dimensions | 63.2 x 30 x 18.8 mm (including back clip) |
| Weight | 28.6g |
| Charging Time | 32 hours |
| Battery Life | About 8 hours |
| Output Power 1 (Single-ended) | L+R ≥ 100mW + 100mW (320 SE, THD+N < 1%) |
| Output Power 2 (Single-ended) | L+R ≥ 10mW + 10mW (300Ω SE, THD+N < 1%) |
| Output Power 3 (Balanced) | L+R ≥ 220mW + 220mW (320 BAL, THD+N < 1%) |
| Output Power 4 (Balanced) | L+R ≥ 55mW + 55mW (300Ω BAL, THD+N ≤ 1%) |
| Frequency Response | 20Hz ~ 40kHz (-3dB) |
| Signal-to-Noise Ratio | ≥ 128dB (A-weighted) |
| Noise Floor | PO < 1V (A-weighted); BAL < 1uV (A-weighted) |
| Output Impedance | < 0.60Ω (32Ω load) |
| THD+N | < 0.0018% (1kHz/-4dB@320Ω) |
Overview of the FiiO BTR13
The FiiO BTR13 stands out because of its multifunctionality. It’s designed to cater to a variety of audio needs, making it a versatile tool for enhancing audio quality across multiple devices. The BTR13 primarily serves three roles:
USB DAC for PCs and Macs:
Acting as an external sound card, the BTR13 connects via USB, significantly improving the audio output of computers and streaming devices. This function is essential for users looking to bypass the often inferior internal sound cards in their laptops or desktop computers, elevating their listening experience to a higher level.
Dongle DAC for Smartphones:
Modern smartphones, especially those lacking 3.5mm headphone jacks, require a reliable dongle DAC to deliver premium sound quality. The BTR13 fits this need perfectly. Using either a USB-C or Lightning connection, it delivers an enhanced audio experience directly from your phone.
Bluetooth DAC:
The BTR13 doesn’t stop at wired connections. It’s also capable of receiving high-resolution audio streams from a variety of Bluetooth-enabled devices. The BTR13 turns your Bluetooth connection into a high-quality sound system by offering support for multiple codecs that maintain the integrity of your music or podcasts.
The magic behind the BTR13’s performance lies in its components. FiiO has equipped this device with Qualcomm’s QCC5125 Bluetooth chip, a chipset known for its efficiency in processing high-quality audio signals and ensuring stable connectivity. Furthermore, dual Cirrus Logic CS43131 DACs handle the digital-to-analog conversion, which is critical for delivering the high-fidelity sound that FiiO products are known for. These DACs work in tandem to process audio signals separately for each channel, reducing distortion and crosstalk, resulting in crystal-clear sound.
Design and Display
The BTR13 is not only powerful but also designed for convenience and portability. Weighing just 28.6g, it’s lighter than many similar devices on the market. The compact design allows it to be easily carried in a pocket or clipped onto clothing or a bag using the included back clip.
The device features a 0.96-inch color IPS display, which provides detailed information at a glance. The display shows critical data such as battery life, volume levels, and connectivity status, ensuring that users always know the status of their device. The display supports both English and Chinese, making it accessible to a global audience.
Despite its small size, the BTR13 is built to be durable and user-friendly. The overall build quality is solid, and the compact form factor makes it an excellent option for users who prioritize portability without sacrificing sound quality.
Key Features and Performance
The FiiO BTR13 is not just a compact DAC and amplifier; it’s a feature-rich device designed to enhance your audio experience across a wide range of devices and setups. Its connectivity options and high-resolution output make it a standout product in its price range.
Versatile Connectivity and Usage
The BTR13 excels in versatility. It’s designed to be compatible with a variety of devices, making it a one-stop solution for anyone looking to improve their audio experience. The device supports three main modes of operation:
PC Mode:
In this mode, the BTR13 functions as an external sound card when connected to a computer via USB. It processes the digital audio signal from your computer and outputs a clean, amplified sound that outperforms most built-in sound cards. This is ideal for audiophiles who want to improve their music listening experience or gamers seeking enhanced sound immersion.
Bluetooth Mode:
Wireless operation is where the BTR13 truly shines. It operates independently of any external power source, running on its internal battery, and streams high-resolution audio from Bluetooth-enabled devices like smartphones, tablets, or even some smart TVs. It’s a portable solution that frees you from being tethered to a specific device while still delivering excellent sound quality.
Phone Mode:
When connected to a smartphone via a USB cable, the BTR13 acts as a dongle DAC, bypassing the phone’s internal audio processor. This significantly improves the audio output, especially on devices that lack high-quality sound chips. The internal battery ensures that the device doesn’t drain your phone’s power while delivering superior sound performance on the go.
High-Resolution Audio and Output
The BTR13 supports audio playback up to 24-bit/96kHz PCM, which is a critical specification for maintaining high-resolution sound. It also utilizes Qualcomm’s QCC5125 chip for Bluetooth transmission, a chipset that is capable of supporting high-resolution audio codecs like AAC, SBC, aptX, aptX LL, aptX Adaptive, and LDAC. These codecs ensure that the BTR13 can maintain high-quality audio transmission even over Bluetooth, preserving the richness and detail in your music or media.
The dual Cirrus Logic CS43131 DACs further contribute to this device’s high-quality output. By processing each channel separately, these DACs reduce crosstalk and enhance clarity, providing a more immersive and accurate listening experience. This setup makes the BTR13 particularly well-suited for audiophiles who appreciate subtle details in their music.
The BTR13 offers two headphone output options:
3.5mm Single-Ended Output:
Capable of delivering 100mW of power into 32 Ohms, this standard headphone jack is ideal for most consumer headphones and IEMs (in-ear monitors).
4.4mm Balanced Output:
For users with higher-end headphones or those requiring more power, the balanced output delivers a whopping 220mW into 32 Ohms, a 282% increase in power compared to FiiO’s previous model, the BTR3K. Balanced connections provide better channel separation and lower noise, resulting in a cleaner and more powerful audio experience.
Parametric Equalization (PEQ)
One of the standout features of the BTR13 is its 10-band parametric equalizer (PEQ). Most devices in this price range offer limited or no equalization options, but the BTR13 goes above and beyond by providing a fully adjustable PEQ. This feature allows users to customize the audio output to their liking, whether they want to tweak the bass, mids, or treble, or correct specific frequency response issues with their headphones.
The parametric EQ can be controlled via the FiiO Control app, available on both iOS and Android or through FiiO’s web portal. This level of control makes the BTR13 a flexible tool for tailoring your audio experience to your personal preferences. Whether you’re a bass-head who wants more thump or a purist who prefers a neutral sound, the BTR13 can be adjusted to suit your needs.
The EQ functionality is available in both Bluetooth and USB DAC modes, making it a versatile feature that enhances the BTR13’s appeal as a comprehensive audio solution.
Comparative Analysis: BTR13 vs. BTR15
FiiO has a range of Bluetooth DACs in its lineup, and the FiiO BTR13 is positioned as a budget-friendly option compared to the more premium FiiO BTR15, which is priced at $132. While both devices offer high-quality audio and advanced features, there are key differences between them that might influence your choice depending on your needs and budget.
BTR13:
- Supports up to 24-bit/96kHz PCM audio.
- Lacks DSD (Direct Stream Digital) and MQA (Master Quality Authenticated) support.
- Weighs 29g.
- Offers both 3.5mm single-ended and 4.4mm balanced outputs with specific power ratings (100mW for single-ended, 220mW for balanced).
BTR15:
- Supports up to 32-bit/384kHz PCM and DSD256, which offers even higher resolution and clarity.
- Includes support for MQA, a format designed to deliver master-quality sound.
- Weighs 37g.
- Offers higher output power than the BTR13, making it better suited for more demanding headphones.
While the BTR13 lacks some of the advanced features found in the BTR15, it offers incredible value for its price and is more than sufficient for most users.
Application and Portability
The portability of the FiiO BTR13 is one of its strongest selling points. Weighing just 28.6g, it’s incredibly light and compact, making it easy to carry with you wherever you go. Its independent power supply system ensures that it delivers optimal performance, even when used on the go, without relying on external power sources.
Whether you’re commuting, working at a desk, or lounging at home, the BTR13 offers a convenient way to elevate your audio experience. The included back clip allows you to attach it to your clothing or bag, further enhancing its portability. The device’s ability to work with a wide variety of headphones, from basic earbuds to high-end models, makes it a versatile solution for any listening environment.
User Experience and Controls
The FiiO BTR13 is designed with user convenience in mind. Its controls are intuitive and easy to use, with several dedicated buttons that make navigating its features a breeze:
- Power Button: Used to turn the device on or off and access the menu.
- Multifunction Button: Handles tasks like reconnecting to devices, playing or pausing music, answering or hanging up calls, and even activating voice assistants.
- Volume Controls: Allow users to adjust the volume, skip tracks, and navigate through submenus.
Conclusion
The FiiO BTR13 is an incredibly versatile and powerful audio accessory that offers an unbeatable value at just $64. Whether you’re an audiophile seeking high-resolution sound, a commuter looking for wireless convenience, or a smartphone user needing a reliable DAC dongle, the BTR13 covers all the bases. Its combination of Bluetooth and USB DAC functionality, extensive equalization options, and robust performance make it a fantastic choice for anyone looking to improve their listening experience.
With its compact size, portability, and advanced features like Car Mode and all-around in-line controls, the BTR13 proves that high-quality audio doesn’t have to come at a high price. It’s a must-have tool for anyone serious about sound quality, offering exceptional performance in a package that’s as portable as it is powerful.
